TS-904
Microphone, long
TS-904
The TS-904 is a designed microphone for exclusive use with the conference units of the Infrared Conference system. Ring type In-Use lamp located at the microphone head permits displaying the operation status of the conference units.
- For Chairman‘s & Delegate‘s Unit
Type
Electret condenser microphone
Directivity
Unidirectional
Impedance
1.8 kΩ
Sensitivity
-37 dB (1 kHz 0 dB = 1 V/Pa)
Frequency Response
100 Hz - 13 kHz
Output Terminal
Equivalent to XLR-4-32
LED Indicator
Speech indicator (ring type)
Operating Temperature
0 °C to +40 °C (32 °F to 104 °F)
Operating Humidity
90 %RH or less (no condensation)
Finish
Gooseneck: Stainless steel, black
Other: ABS resin, black
Other: ABS resin, black
Weight
105 g (0.23 lb)
Compatible Unit
Chairman/Delegate units: TS-801, TS-802, TS-901, TS-902
Please download Datasheet to access full specifications.
Long Gooseneck microphone for large tables etc. with red lights ring to display talk released, with removable wind / pop shield. 4-pin XLR connector for connection to the delegate and Chairman units of infrared Conference systems TS-800/TS-900.
