VX-3000PM

Preamp Matrix Panel

VX-3000PM

The VX-3000PM is a preamplifier matrix panel designed for exclusive use with the VX-3000 Series. The number of audio inputs, control inputs, and control outputs can be increased by connecting the VX-3000PM to the VX-3000 Frame via network. It is equipped with 8 audio inputs and their corresponding volume controls, 20 control inputs, and 10 control outputs. A single VX-3000PM unit can be connected to a single VX-3000 Frame, and a maximum of 40 units can be configured per system. Unicast audio transmission can be made among the VX-3000PM units, enabling broadcast activation and microphone announcement at multiple places. It can be mounted in an EIA equipment rack (1U size).

Preamplifier matrix panel enabling the additional audio inputs,control inputs and control outputs to the VX-3000 syste
Equipped with 8 audio inputs with volume controls, 20control inputs and 10 control outputs
Provides unicast audio streaming functionality.
Unicast audio streaming is possible among VX-3000PMs.
1 unit can be connected to a single VX-3000 Frame and a maximum of 40 units can be configured per system
