PD-1535S-AS

PD-1535S-AS 1

Power Sequencer

PD-1535S-AS

Extend the life of your equipment through proper power supply sequencing. The TOA power sequencer helps to prevent AC power breakers tripping and protects your equipment from high power surges. Using a power sequencer to ensure proper equipment shutdown, you can prevent noise generated by front-end equipment and also prevent damaging your speakers. Designed with 5 AC outputs and 2 speaker zones, it has selectable delay of power on and off and can cascade up to 4 units. It is your ideal sequencing choice.

Sqequencially power output ON and OFF (delay time 1 sec.)
Dry contact to control sequence remotely
Up to 4 units connectable
Fuse proteced for AC output
External earth connection
Up to 16 A in total
Up to 5 socket
Have speaker zone

Specifications Downloads

Power Source

AC 220 - 230 V, 50/60 Hz, Max. 3500 W
Max. load 16 A

Input

2 channels: 100 V from amplifier, Max. load 500 W each channel

Output

2 channels: to speaker lines, Max. load 500 W each channel

AC Outlet

5 AC outlets, Universal type (3 pin plug), 10 A

Indicator

Power Indicator light green
Sequence Indicator light green

Control

2 Input, 2 Output
No-voltage make contact input, open voltage: 5 V DC,
Short-circuit current: Under 5 mA, Removable terminal block (6 pins)

Cascade

Max. 4 units

Step Timing

1 Second per AC outlet (factory preset)

Operating Temperature

0 °C to 40 °C

Operating Humidity

Under 90 %RH (no condensation)

Finish

Front Panel: Aluminum, Hairline, Painting Black
Case: Steel Plate, Painting Black

Dimensions

482 (W) × 44 (H) × 326.5 (D) mm

Weight

3.5 kg

Included Accessories

Removable terminal plug (6 pins) x 2
Removable terminal plug (3 pins) x 2
